APP:

V380 Pro

System structure:

Embedded Linux system, ARM chip structure

Chip:

AK3918E V331

Resolution:

5.0MP

Sensor Resolution:

1/2.9"COMS SC2232H/GC4653

Lens:

Fisheye lens (1.35±3%mm)

Lens view angle:

360°

View angle:

Horizontal: 185°/ Vertical:185°

Video compression standard:

H.265/20FPS

Video format:

PAL

Minimum illumination:

0.01Lux@（F2.0，VGC ON),O.Luxwith IR

Electronic shutter:

Auto

Backlight compensation:

Support

Noise reduction:

2D、3D

Led quantity:

3pcs white LED + 3PCS infrared LED

Network connection:

Support WIFI, AP hotspot

Network:

WIFI wireless transmission (support IEEE802.11b/g/n wireless protocol).

Night vision:

IR-CUT switch Automatic，about 5-8meters (It varies from environment)
White Led can be remote control via APP:①Turn ON ②Turn OFF ③ Auto
(In automatic mode, the infrared light will be turned ON after the IR-cut switch to night vision automatically , it can
intelligently detected human body, and Turn ON/OFF the White light intelligently )

Audio

Built-in microphone and speaker, support two-way audio and real-time transmission.
ADPCM audio compression standard, self-adapt to code stream

Network protocol:

TCP/IP、UDP、RTSP、HTTP
DDNS、DHCP、FTP、NTP

Alarm:

①Motion detection and picture push ②AI Human intrusion Detection (optional)

ONVIF:

Support ONVIF

Storage:

TF Card（Max 128G）；Cloud storage /Cloud disk (optional)

Connection Port:

Standard E27 base

Power input:

110~220V

Work environment:

Working temperature:-10℃ ~ + 50℃ Working Humidity: ≤95%RH
