APP:

v380 Pro

System structure:

Embedded Linux system, ARM chip structure

Chip.

AK3918E-V300

Resolution:

2MP

View angle:

80°

Lens:

3.6MM

Pan-tilt:

Rotates Horizontal:350° Vertical: manual 65°

Preset point quantity:

4 pcs

Video compression standard

H.265/25FPS (HD 1080P)

Minimum illumination:

0.02Lux@(F2.0， vGc ON),O.Luxwith lR

Electronic shutter:

Auto

Backlight compensation:

support

Antenna:

Buit-in antenna

Led quantity:

4pcs lnfrared LED

Network connection:

WIFl wireless transmission (support IEEE802.11blg'n wireless
protocol).Support AP Hotspot

RJ45 Netowork port:

Without

Night vision

IR-CUT switch Automatic，about 8meters (lt varies from environment)

Audio:

Built-in microphone and speaker, support two-way audo and real-time
transmission.
ADPCM audio compression standard, selfadapt to code stream

Alarm:

1.Motion detection and picture push 2.AI Human intrusion
Detection (optional)

ONVIF

Support ONVIF

Storage:

TF Card (Max 128G）;Cloud storage /Cloud disk card(optional)

Power input:

5V/1.5A (US /EU plug optional)

Work environment:

Working temperature:-10℃~+50℃ Working Humidity:≤95%RH
