APP:

V380 Pro

System structure:

Embedded Linux system,ARM chip structure

Chip.

MSC313E(Mstar)

Resolution:

3.0MP

Sensor Resolution:

|1/2.9"cOMs sC2232HGC2063 2304*1296

Lens:

3.6MM

View angle:

75°

Pan-tilt:

Rotates Horizontal:355° Vertical: 60°

Preset point quantity:

6 pcs

Video compression standard

H.265/12FPS

Minimum illumination:

0.02Lux@(F2.0,vGC ON),O.Luxwith IR

Electronic shutter:

Auto

Backlight compensation:

support

Noise reduction:

2D、3D

LED quantity:

6pcs white LED

Network:

WIFI wireless transmission (support IEEE802.11bgn wireless protocol),
Support Ap hotspot ,
adapt to RJ45 Network port.

Night vision

IR-CUT switch Automatic，about 5-8meters (lt varies from environment)

Audo:

Built-in microphone and speaker, support two-way audo and real-time
transmission.
ADPCM audo compression standard, self-adapt to code stream

Network protocol:

TCP/IP .uDP.RTSP.HTTPDDNS .DHCP、FTP、NTP

Alarm:

1.Motion detection and picture push 2.Al Human intrusion Detection(option

ONVIF

Support ONVIF

Storage:

TF Card (Max128G)﹔ Cloud storage /Cloud disk (optional)

Power input:

5V/1.6A

Work envronment:

Working temperature:-10℃~+50℃ Working Humidity: ≤95%RH
