Network

W ireless W iFi
frequency

2.4 GHz

IEEE802. 11b, 802. 11g, 802. 11n Draft

Support

N/A

5.0 GHz

N/A

N/A

N/A

4G nano SIM
card

Southeast Asia

B1/B3/B5/B8/B34/B38/B39/B40/B41

N/A

Support

Australia

B1/B2/B3/B4/B5/B7/B8/B28/B40/B66

N/A

Support

Japan

B1/B3/B8/B18/B19/B26

N/A

Support

America

B2/B4/B5/B12/B13/B14/B25/B26/B41/B66/

N/A

Support

Europe

B71

N/A

Support

Video

Master sensor

1080P

lngenic T31ZL+2063

1440P

lngenic T31ZX+4653

Resolution

Main stream: 1920x 1080@ 15fps, Sub stream: 640x360@ 15fps

Format

Compression format

H.265

Video file format

MP4

Lens

4mm F2.0 lens, Low lux., wide view angle: 120 degrees. 4X digital zoom

Night vision

6pcs array infrared LEDs, night vision distance 30m . Full-colorful day/night

Audio

Compression

G.726/AAC. Audio code rate: 8Kbps, 16bit

Input/Output

Built-in MIC and Speakers, support two way audio

Alarm

PIR motion
detection

Support max 12 meters PIR detection range.

Alarm linkage

Alarm record videos to Micro SD card;Alarm mobile phone message push

Video storage

Memory card

Support up to 128G micro SD card. Support cloud storage

Record

PIR alarm recording.

Replay

Support App remote play and download the video

Power supply

Solar panels

6W monocrystalline silicon solar panel

Battery

Built-in 3 pcs 18650 battery, total volume max 9600mAh

Operating mode

Low power working mode

Wake-up method

PIR alarm wake up, remote manual wake up

Hibernation

W hen alarm end or remote connection disconnected.

Power
consumption

Sleeping stand-by power: 0.03W; Working: 1.3W@days/3W@night

PTZ

Rotation angle

Horizon Pan: 0°~355°, Vertical Tilt: 0°~120°

Spinning speed

Horizontal speed: 10°~ 30°/S; Vertical speed: 8°~ 25°/S

Other

Power input

DC5V 2A

Environment

Environment -20℃~+60℃(-4℉~+140℉), Humidity 10%~80%, non-conden

Shell material

ABS fireproof plastic material, vandal-proof, waterproof level IP65

Power cable

Type-c interface, extension cable 3 meters

Product Size

223mm×170mm×230mm(L×W×H)

Package
dimensions

290x218x 135mm(L×W×H); Product weight: 1.78kg

Packing list

IP Camera, Antenna, Solar panel, Support, Mounting screws, Screwdriver, USB cable, Manual,Cable tie

Mode ：Q5

Ve s o

Ba d

W F

4G

Network

W ireless W iFi
frequency

2.4 GHz

IEEE802. 11b, 802. 11g, 802. 1 1n Draft

Support

N/A

5.0 GHz

N/A

N/A

N/A

4G nano SIM
card

Southeast Asia

B1/B3/B5/B8/B34/B38/B39/B40/B41

N/A

Support

Australia

B1/B2/B3/B4/B5/B7/B8/B28/B40/B66

N/A

Support

Japan

B1/B3/B8/B18/B19/B26

N/A

Support

America

B2/B4/B5/B12/B13/B14/B25/B26/B41/B66/

N/A

Support

Europe

B1/B3/B5/B7/B8/B20/B38/B40/B41

N/A

Support

Video

Master sensor

1080P

lngenic T31ZL+2063

1440P

lngenic T31ZX+4653

Resolution

Main stream: 1920x 1080@ 15fps, Sub stream: 640x360@ 15fps

Format

Compression format

H.265

Video file format

MP4

Lens

4mm F2.0 lens, Low lux., wide view angle: 120 degrees. 4X digital zoom

Night vision

6pcs array infrared LEDs, night vision distance 30m . Full-colorful day/night

Audio

Compression

G.726/AAC. Audio code rate: 8Kbps, 16bit

Input/Output

Built-in MIC and Speakers, support two way audio

Alarm

PIR motion
detection

Support max 12 meters PIR detection range.

Alarm linkage
