Module

Hisilicon Hi3861 low power wi-fi chip

Qualcomm High pass chip custom low power module

Frequency

2.4Gwifi

Support full spectrum 4G networks in the us, Europe and China

Distribution network

Qr code scanning+Wi-Fi Quick link

Qr code scanning

SIM card

Not Supported

Nano SIM

WiFi hotspot

Not Supported

Not Supported

Protocol

TCP/IP, HTTP, TCP, UDP, SMTP, DHCP, DNS, P2P

Main Domain Controller

Hisilicon Hi3518EV300

Image Sensor

300W CMOS sensor SC2335 1/2.8

Video Streaming

3MP/15fps 640*360/30fps

Mobile detection

PIR+motion detection+humanoid detection multiple intelligent detection, effective distance 10-15 meters

Night vision mode

850nm infrared + white light mode, APP selection

Night vision distance

Effective lighting distance is about 15-30 meters

Camera lens

3MP Yutong HD lens 3.6MM F=2.8 Horizontal FOV 120 degrees

Battery

4*21700 lithium battery, solar rechargeable battery

Charge

10W solar continuous charging, supports USB port charging for about 16 hours to fully charge

Wake up/sleep time

15s do not sleep

System

Lite OS

Audio

Audio codec

AAC and G.726

MIC

High sensitivity -38dB

Video

Video code

H264/H265

Features

AEESS

Support

ANGLE

Horizontal: 355° Vertical: 90°

Key

Power/reset key Power/reset key

Status

Blue & Red LED

Memorizer

Support TF Card 4GB-128GB and cloud storage

Playback

Event list playback and cloud storage playback

Grade of waterproof

IP66

Full duplex intercom

support

APP

Tuya Smart, ios10.0, android5.0

Environment

Temperature

-30℃ ~+60℃

Humidity

≤80%RH

Package

Package Size

29*18*15CM

Package weight

1.7KG

Single box size

59*46*32CM

Single box weight

21.8KG

Quantity per box

12 sets
